1. GENERAL DATA
A. General Conditions
Refer to Subject 20-10-11 for the conditions that are applicable for the insulation of the free end of a
wire or cable.
2. PART NUMBER AND DESCRIPTION
A. End Cap Part Numbers
Table 1
END CAP PART NUMBERS
Part Number Description Supplier
324484 Crimp type, without insulation removal Tyco (AMP)
324485 Crimp type, without insulation removal Tyco (AMP)
324486 Crimp type, without insulation removal Tyco (AMP)
324487 Crimp type, without insulation removal Tyco (AMP)
328307 Crimp type, with insulation removal Tyco (AMP)
328308 Crimp type, with insulation removal Tyco (AMP)
328309 Crimp type, with insulation removal Tyco (AMP)
328854 Crimp type, without insulation removal Tyco (AMP)
328855 Crimp type, without insulation removal Tyco (AMP)
328856 Crimp type, without insulation removal Tyco (AMP)
328857 Crimp type, without insulation removal Tyco (AMP)
328858 Crimp type, without insulation removal Tyco (AMP)
328859 Crimp type, without insulation removal Tyco (AMP)
328860 Crimp type, without insulation removal Tyco (AMP)
328861 Crimp type, without insulation removal Tyco (AMP)
329638 Crimp type, without insulation removal Tyco (AMP)
BACT63D1 Heat Shrinkable Boeing
BACT63D2 Heat Shrinkable Boeing
BACT63D3 Heat Shrinkable Boeing
Table 2
CRIMP TYPE END CAPS WITHOUT INSULATION REMOVAL
Wire O.D.
(inch)
End Cap
Minimum Maximum
Temperature
Grade
Class Part Number
Color
Body Ring A Ring B
0.036 0.043 D 1 328854 - Red Green
0.044 0.051 D 1 328855 - Blue Green
