Table 2 CRIMP TYPE END CAPS WITHOUT INSULATION REMOVAL (Continued)
Wire O.D.
(inch)
End Cap
Minimum Maximum
Temperature
Grade
Class Part Number
Color
Body Ring A Ring B
0.048 0.075 A 2 324484
Transparent
(White)
- -
0.052 0.056 D 1 328856 - Yellow Green
0.056 0.064 D 1 328857 - Brown Green
0.065 0.074 D 1 328858 - Violet Green
0.075 0.087 D 1 328859 - Black Orange
0.080 0.115 A 2 324485 Red - -
0.088 0.110 D 1 328860 - Gray Orange
0.111 0.150 A 1 329638 Brown - -
0.120 0.145 A 2 324486 Blue - -
0.125 0.138 D 1 328861 - Nickel Nickel
0.150 0.210 A 2 324487 Yellow - -
Table 3
CRIMP TYPE END CAPS FOR A WIRE WITH INSULATION REMOVAL
Wire Size
(AWG)
Maximum Wire
O.D.
(inch)
End Cap
Minimum Maximum
Temperature
Grade
Class Part Number Color
22 18 0.124 A 2 328307 Red
16 14 0.149 A 2 328308 Blue
12 10 0.210 A 2 328309 Yellow
Table 4
HEAT SHRINKABLE END CAPS
Wire O.D.
(inch)
End Cap
Minimum Maximum
Temperature
Grade
Class Boeing Standard Color
0.030 0.063 B 2 BACT63D1 White
0.050 0.125 B 2 BACT63D2 Red
0.100 0.250 B 2 BACT63D3 Grey
ASSEMBLY OF END CAPS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-16
Page 3
Oct 15/2015D6-54446
