Table 30 ALTERNATIVE REMOVABLE CONTACT SPLICES (Continued)
Specified Removable Contact Splice Alternative Removable Contact Splice
Part Number Supplier Part Number Supplier
AIS16R AIE AIS16R-1 AIE
Table 31
APPROVED SUPPLIERS OF BOEING STANDARD CONTACTS FOR REMOVABLE CONTACT SPLICES
Contact Supplier
BACC47CN2()
Amphenol
Framatome
Pyle-National
Tri-Star
BACC47CP2()
Amphenol
Framatome
Pyle-National
Tri-Star
H. Tyco/Amp 6960() and 2157() Breakaway Wire Splice Part Numbers
The Tyco/Amp 6960() and 2157() Breakaway Wire Splice is a single wire in line splice.
Refer to Paragraph 18. for the assembly procedures for these splices.
Table 32
TYCO/AMP 6960() AND 2157() BREAKAWAY SPLICES AND THE RELATED CRIMP TOOLS
Splice Part Number Wire Size
(AWG)
Insulating Sleeve
Part Number
Crimp Tool Head Part
Number
Die Set Part Number
696087-1 3/0 8447-8 69066 1320444-1
696087-1 3/0 8447-8 58422-1 1320444-1
696096-1 2 8445-7.5 69066 1320447-1
696096-1 2 8445-7.5 58422-1 1320447-1
2157581-1 3/0 8447-8 69066 1320444-1
2157581-1 3/0 8447-8 58422-1 1320444-1
2157580-1 2 8445-7.5 69066 1320447-1
2157580-1 2 8445-7.5 58422-1 1320447-1
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 29
