TABLE OF CONTENTS
PARAGRAPH PAGE
1. GENERAL DATA 2
A. General Conditions 2
B. Configuration of Splices on Adjacent Power Feeder Wires 2
2. SELECTION OF SPLICES
3
A. Selection of Standard Butt Splices 3
B. Selection of Transitional Butt Splices 5
3. PART NUMBERS AND DESCRIPTION
6
A. Copalum Splice Part Numbers 6
4. ASSEMBLY OF COPALUM SPLICES
9
A. Necessary Materials 9
B. Wire Preparation - AMP 277156-1 and AMP 277157-1 Splices with AWG 10 Wire 10
C. Wire Preparation - AMP 277156-1 Splices with AWG 8 Wire 11
D. Wire Preparation - Splices with other Wire Size Combinations 12
E. Wire Preparation- BACS52N Splices 13
F. Increase of the O.D. of the Wire with Layers of Tape 15
G. Increase of the O.D. of the Wire with Heat Shrinkable Sleeves 16
H. Splice Assembly 16
I. Insulation of the Splice - AMP 277156-1 and AMP 277157-1 Splices with AWG 10 Wire 27
J. Insulation of the Splice - AMP 277156-1 Splices with AWG 8 Wire 31
K. Insulation of the Splice - BACS52N Splices and Splices with other Wire Size
Combinations 31
5. REPAIR OF COPALUM SPLICES 36
A. Repair of the Insulation of a Splice Assembly 36
B. Splice Removal 38
707, 727-787
STANDARD WIRING PRACTICES MANUAL
ASSEMBLY AND REPAIR OF THE AMP AND BACS52N COPALUM SPLICES
20-30-13
Page 1
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
