Boeing 707 - Uninsulated Butt Splices

Table 10 PART NUMBERS OF INSULATED BUTT SPLICES (Continued)
CAU Range
Part Number
Crimp Barrel
Size
Description
Insulation
Color
Supplier
Minimum Maximum
527 837 NAS1389-10 2 No Insulation Grip Red QPL
838 1195 NAS1389-13 1/0 No Insulation Grip Blue QPL
Table 11
APPROVED SUPPLIERS OF INSULATED BUTT SPLICES
Splice Supplier
NAS1388-1 Tyco/ AMP
NAS1388-2 Tyco/ AMP
NAS1388-3 Tyco/ AMP
NAS1388-4 Tyco/ AMP
NAS1388-5 Tyco/ AMP
NAS1389-1 Tyco/ AMP
NAS1389-4 Tyco/ AMP
NAS1389-7 Tyco/ AMP
NAS1389-10 Tyco/ AMP
NAS1389-13 Tyco/ AMP
C. Uninsulated Butt Splices
Table 12
PART NUMBERS OF BUTT SPLICES
CAU Range
Part Number Crimp Barrel Size Supplier
Minimum Maximum
3 15 BACS52K1 26-20 Boeing
7 24 NAS1387-4 22-18 QPL
8 27 BACS52K2 20-16 Boeing
15 51 NAS1387-5 16-14 QPL
19 67 BACS52K3 16-12 Boeing
65 104 BACT12C12 12-10 Boeing
43 138 NAS1387-6 12-10 QPL
132 181 BACT12C8 8 Boeing
132 181 BACT12C8NK 8 Boeing
206 288 BACT12C6 6 Boeing
206 288 BACT12C6NK 6 Boeing
327 457 BACT12C4 4 Boeing
327 457 BACT12C4NK 4 Boeing
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 17
Feb 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
