Boeing 707 - Cable Preparation - Special Configuration

Make sure that the small end of the sleeve is put on first.
C. Cable Preparation - Special Configuration
For the conditions that are applicable for this procedure, refer to Paragraph 2.A..
Table 7
CABLE PREPARATION
Splice Kit Part
Number
Cable
Configuration
Dimension
Length
(inch)
Special Instructions Reference
Target Tolerance
BACS52R2T1
2 Cables, 1 AWG
22 or AWG 24
Conductor
A 1.00 ±0.02
-
Figure 17
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 1 AWG
24 Conductor
A' 0.90 ±0.02
Fold the conductor back.
Fold the shield back
B' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R2T1
2 Cables, 1 AWG
22 or AWG 24
Conductor
A 1.00 ±0.02
-
Figure 17
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 1 AWG
22 Conductor
A' 1.30 ±0.02
Fold the conductor backB' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R2T1
1 Cable, 1 AWG
16, AWG 18, or
AWG 20
Conductor
A 1.00 ±0.02
-
Figure 16
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 1 AWG
24 Conductor
A' 0.90 ±0.02
Fold the conductor back.
Fold the shield back
B' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R2T1
1 Cable, 1 AWG
16, AWG 18, or
AWG 20
Conductor
A 1.00 ±0.02
-
Figure 16
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 1 AWG
22 Conductor
A' 1.30 ±0.02
Fold the conductor backB' 0.38 ±0.02
C' 0.56 ±0.02
ASSEMBLY OF BACS52R SHIELDED SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-19
Page 20
