Table 7 CABLE PREPARATION (Continued)
Splice Kit Part
Number
Cable
Configuration
Dimension
Length
(inch)
Special Instructions Reference
Target Tolerance
BACS52R2T1
1 Cable, 1 AWG
22 Conductor, 1
Cable, 1 AWG 24
Conductor
A 1.00 ±0.02
-
Figure 17
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 1 AWG
22 Conductor
A' 1.30 ±0.02
Fold the conductor backB' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R2T2
2 Cables, 2 AWG
22 Conductors
A 2.10 ±0.02
-
Figure 20
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 2 AWG
22 Conductors
A' 2.38 ±0.02
Fold the conductor backB' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R2T2
1 Cable, 2 AWG
16, AWG 18 or
AWG 20
Conductors
A 2.10 ±0.02
Fold the conductors back
Figure 19
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 2 AWG
22 or AWG 24
Conductors
A' 2.38 ±0.02
Fold the conductor backB' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R2T4
1 Cable, 2 AWG
22 or AWG 24
Conductors
A 2.38 ±0.02
Fold the conductors back
Figure 18
B 0.38 ±0.02
C 0.56 ±0.02
1 Cable, 2 AWG
22 or AWG 24
Conductors
A' 2.38 ±0.02
Fold the conductors backB' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R2T4
2 Cables, 2 AWG
22 or AWG 24
Conductors
A 2.10 ±0.02
-
Figure 20
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 2 AWG
22 or AWG 24
Conductors
A' 2.38 ±0.02
Fold the conductors backB' 0.38 ±0.02
C' 0.56 ±0.02
ASSEMBLY OF BACS52R SHIELDED SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-19
Page 21
Oct 15/2015D6-54446
