Table 7 CABLE PREPARATION (Continued)
Splice Kit Part
Number
Cable
Configuration
Dimension
Length
(inch)
Special Instructions Reference
Target Tolerance
BACS52R2T4
2 Cables, 2 AWG
26 Conductors
A 2.38 ±0.02
Fold the conductors back
Figure 21
B 0.38 ±0.02
C 0.56 ±0.02
2 Cables, 2 AWG
26 Conductors
A' 2.38 ±0.02
Fold the conductors backB' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R3T1
1 Cable, 1 AWG
12 Conductor
A 1.00 ±0.02
-
Figure 16
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 1 AWG
18 or AWG 20
Conductor
A' 0.90 ±0.02
Fold the conductor back.
Fold the shield back
B' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R3T1
2 Cables, 1 AWG
16, AWG 18, or
AWG 20
Conductor
A 1.00 ±0.02
-
Figure 17
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 1 AWG
18 or AWG 20
Conductor
A' 0.90 ±0.02
Fold the conductor back.
Fold the shield back
B' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R3T2
1 Cable, 2 AWG
12 Conductors
A 2.10 ±0.02
-
Figure 23
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 2 AWG
20 Conductors
A' 2.00 ±0.02
Fold the conductor back.
Fold the shield back
B' 0.38 ±0.02
C' 0.56 ±0.02
BACS52R3T2
1 Cable, 2 AWG
14 Conductors
A 2.10 ±0.02
-
Figure 23
B 0.38 ±0.02
C 0.28 ±0.02
1 Cable, 2 AWG
20 Conductors
A' 2.00 ±0.02
Fold the conductor back.
Fold the shield back
B' 0.38 ±0.02
C' 0.56 ±0.02
ASSEMBLY OF BACS52R SHIELDED SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-19
Page 22
Oct 15/2015D6-54446
