Table 11 CRIMP TOOLS FOR BACT12AW AND BACT12AY TERMINAL LUGS (Continued)
Terminal Lug
Crimp Barrel Size
(Part Mark)
Crimp Tool
Power Unit Head Die Set
BACT12AW-6C 2/0 AL 69120
1752787-1
68011-1
58422-1
69066 314964-1
BACT12AW-8C 4/0 AL 69120
1752787-1
314948-1
58422-1
BACT12AY-5C 1/0 AL 69120
1752787-1
68010-258422-1
69066
BACT12AY-6C 2/0 AL 69120
1752787-1
68011-158422-1
69066
BACT12AY-8C 4/0 AL 69120
1752787-1
314948-1
58422-1
(1) Make a selection of insulation sleeve. Refer to Paragraph 2.F..
(2) Remove the necessary length of the wire insulation.
Refer to:
• Table 10
• Subject 20-00-15 for the procedures to remove the insulation.
(3) Make a selection of a power unit, crimp tool head, and die set from Table 11. Refer to Paragraph
2.H. for terminal assembly process.
C. Wire Preparation for BACT13K Copalum Terminals
Table 12
WIRE INSULATION REMOVAL LENGTH FOR BACT13K TERMINAL LUGS
Terminal Lug
Crimp Barrel Size
(Part Mark)
Removal Length
(inch)
Target Tolerance
BACT13K-1 8AL - 10CU 0.44 ±0.03
BACT13K-2
6AL - 8CU 0.50 ±0.03
BACT13K-24
BACT13K-3
4AL - 6CU
0.69 ±0.03BACT13K-34
BACT13K-3A78 4AL 13-78
