(4) If the splice kit does not have seal inserts and has different size solder sleeves put these
components on Cable A in this sequence:
• The outer sleeve
• The small solder sleeve
• The shield material
• The large solder sleeve.
Make sure that:
• The small end of the small solder sleeve is put on the cable first
• The large end of the large solder sleeve is put on the cable first.
(5) If the splice kit does not have seal inserts and the solder sleeves are the same size:
(a) Put these splice assembly components on Cable A in this sequence:
• The outer sleeve
• A solder sleeve
• The shield material.
Make sure that the small end of the solder sleeve is put on the cable first.
(b) Put the other solder sleeve on Cable B and Cable C.
Make sure that the small end of the solder sleeve is put on the cable first.
(6) Put a seal sleeve on Wire A1.
(7) Put a seal sleeve on Wire A2.
(8) Put a seal sleeve on Wire B3.
5. CONDUCTOR SPLICE ASSEMBLY
A. Assembly of the Conductor Splice
This section gives the procedure to assemble one conductor splice.
For the assembly of the different shielded splices, refer to the procedure that is applicable for the
specified shielded splice kit part number.
(1) Put one half of the conductor splice in the tool. Refer to Figure 42.
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 108
Oct 15/2020D6-54446
