(2) Put the terminal on the stud
(3) Put these washers on the stud in this order:
(a) Flat washer
(b) Lock washer
(4) Put the nut on the stud.
(5) Torque the nut in accordance with Table 17/INSTALLATION HARDWARE FOR BACT12M APU
AND IDG COPPER TERMINALS. Make sure that:
(a) The lock washer is fully compressed.
(b) The terminal does not move on the stud.
M. Installation of Jay-El 10167 Time Delay Terminals
Table 19
PRESSURE WASHER FOR JAY-EL TIME DELAY TERMINALS
Description Material Plating Part Number Supplier
Pressure washer Steel Cadmium AN960-6L An available source
The terminal stud hardware buildup on the 10167-()-() time delays includes a flat, cadmium plated steel
pressure washer between the lock washer and the wire terminal lug.
(1) Put the wire terminal lug on the terminal stud.
(2) Make a selection of a pressure washer from Table 19.
(3) Put the pressure washer on the stud on the lug.
(4) Put the lockwasher on the stud on the pressure washer.
(5) Engage the threads of the top nut and the stud.
(6) Do Step 3.M.(2) through Step 3.M.(5) for the remaining terminals of the Jay-El 10167 Time Delay.
(7) Torque the terminals. Refer to Table 13.
NOTE: The terminal stud size is 6-32.
N. Installation Terminal Torque for the MS27212-() Terminal Block
Refer to Paragraph 2.D. for the configuration of the terminals on the MS27212 terminal block.
