Boeing 707 - Faston Terminal Assembly; Terminal Assembly; Terminal Housings

B. Terminal Housings
Table 3
FASTON TERMINAL HOUSINGS
Faston Terminal
Terminal Housing
PSU System
Part Number Supplier
61873-1 1-480416-0 AMP Passenger Information Signal Section
42640-2 1-480416-3 AMP Speaker Terminal Blue Wire
42640-2 1-480416-4 AMP Speaker Terminal Red Wire
2. FASTON TERMINAL ASSEMBLY
A. Terminal Assembly
Table 4
INSULATION REMOVAL LENGTH
Faston Terminal
Wire Size
(AWG)
Removal Length L
(inch)
Target Tolerance
2-520081-2
22 17/64 ±1/32
20 17/64 ±1/32
18 17/64 ±1/32
2-520103-2
22 0.26 ±1/32
20 0.26 ±1/32
18 0.26 ±1/32
2-520184-4
22 0.26 ±1/32
20 0.26 ±1/32
18 0.26 ±1/32
2-520194-2
22 0.26 ±1/32
20 0.26 ±1/32
18 0.26 ±1/32
2-520129-2
22 9/32 ±1/32
20 9/32 ±1/32
18 9/32 ±1/32
2-520337-2
22 0.26 ±1/32
20 0.26 ±1/32
18 0.26 ±1/32
ASSEMBLY OF AMP (TYCO) FASTON TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-15
Page 3
