Table 4 INSULATION REMOVAL LENGTH (Continued)
Faston Terminal
Wire Size
(AWG)
Removal Length L
(inch)
Target Tolerance
3-520117-2
18
0.27 ±1/32
0.54 (Removal length for
Double Back)
±1/32
16 0.27 ±1/32
14 0.27 ±1/32
41729 16 1/4 ±1/32
42628-2
24 1/2 ±1/32
22 1/2 ±1/32
20 1/4 ±1/32
18 1/4 ±1/32
42640-2
24 1/4 ±1/32
22 1/4 ±1/32
42888-1
24 1/2 ±1/32
22 1/2 ±1/32
20 1/4 ±1/32
18 1/4 ±1/32
55318-3 16 1/4 ±1/32
55319-1 22 1/4 ±1/32
60894-1
22 1/4 ±1/32
20 1/4 ±1/32
18 1/4 ±1/32
61048-1
22 3/16 ±1/32
20 3/16 ±1/32
18 3/16 ±1/32
61048-2
22 3/16 ±1/32
20 3/16 ±1/32
18 3/16 ±1/32
61873-1 16 1/4 ±1/32
640903-1
22 1/2 ±1/32
20 1/4 ±1/32
18 1/4 ±1/32
640909-1
22 1/2 ±1/32
20 1/4 ±1/32
18 1/4 ±1/32
ASSEMBLY OF AMP (TYCO) FASTON TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-15
Page 4
