Table 4 INSULATION REMOVAL LENGTH (Continued)
Faston Terminal
Wire Size
(AWG)
Removal Length L
(inch)
Target Tolerance
640911-1
22 1/4 ±1/32
20 1/4 ±1/32
18 1/4 ±1/32
641877-1 16 3/16 ±1/32
640927-1
16 1/4 ±1/32
14 1/4 ±1/32
Table 5
FASTON TERMINAL CRIMP TOOLS
Terminal
Wire Size
(AWG)
Crimp Tool
Special
Instructions
Basic Unit Position Die Set Tool Cavitiy Supplier
2-520081-2
22 58078-3 - 90390-3 - AMP -
20 58078-3 - 90390-3 - AMP -
18 58078-3 - 90390-3 - AMP -
2-520103-2
22 58078-3 - 90390-3 One Dot, Red AMP -
20 58078-3 - 90390-3 One Dot, Red AMP -
18 58078-3 - 90390-3 One Dot, Red AMP -
2-520184-4
22 58078-3 - 90390-3 One Dot, Red AMP -
20 58078-3 - 90390-3 One Dot, Red AMP -
18 58078-3 - 90390-3 One Dot, Red AMP -
2-520194-2
22 58078-3 - 90390-3 One Dot, Red AMP -
20 58078-3 - 90390-3 One Dot, Red AMP -
18 58078-3 - 90390-3 One Dot, Red AMP -
2-520129-2
22 58078-3 - 90390-3 - AMP -
20 58078-3 - 90390-3 - AMP -
18 58078-3 - 90390-3 - AMP -
2-520337-2
22 58078-3 - 90390-3 One Dot, Red AMP -
20 58078-3 - 90390-3 One Dot, Red AMP -
18 58078-3 - 90390-3 One Dot, Red AMP -
3-520117-2
18 58078-3 - 90391-3 14 AMP -
16 58078-3 - 90391-3 16 AMP -
14 58078-3 - 90391-3 14 AMP -
41729 16 90165-1 - - - AMP -
ASSEMBLY OF AMP (TYCO) FASTON TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-15
Page 5
Feb 15/2021D6-54446
