Table 5 FASTON TERMINAL CRIMP TOOLS (Continued)
Terminal
Wire Size
(AWG)
Crimp Tool
Special
Instructions
Basic Unit Position Die Set Tool Cavitiy Supplier
42628-2
24
59250 - - - AMP
Fold the
Conductor
Back
59824-1 - - - AMP
Fold the
Conductor
Back
22
59250 - - - AMP
Fold the
Conductor
Back
59824-1 - - - AMP
Fold the
Conductor
Back
20
59250 - - - AMP -
59824-1 - - - AMP -
18
59250 - - - AMP -
59824-1 - - - AMP -
42640-2
24
90116-1 1 - - AMP -
90166-1 - - - AMP -
22
90116-1 1 - - AMP -
90166-1 - - - AMP -
42888-1
24
59250 - - - AMP
Fold the
Conductor
Back
59824-1 - - - AMP
Fold the
Conductor
Back
22
59250 - - - AMP
Fold the
Conductor
Back
59824-1 - - - AMP
Fold the
Conductor
Back
20
59250 - - - AMP -
59824-1 - - - AMP -
18
59250 - - - AMP -
59824-1 - - - AMP -
55318-3 16
69875 - 59827-1 - AMP -
59824-1 - - Blue AMP -
55319-1 22 59275 - - Yellow AMP -
ASSEMBLY OF AMP (TYCO) FASTON TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-15
Page 6
Feb 15/2021D6-54446
