D. Hot Air Guns
Table 49
HOT AIR GUNS
Type
Temperature Range
(Degrees C)
Hot Air Gun
Minimum Maximum
Basic Unit Reflector
Part Number Supplier
Part
Number
Supplier
Standard
Temperature
232 371 CV-5300 Tyco/Raychem MG-1 Tyco/Raychem
260 371
CV-5000 Model 500 Tyco/Raychem TG-135 Tyco/Raychem
CV-5000 Model 500B Tyco/Raychem TG-135 Tyco/Raychem
High
Temperature
399 538
CV-5000 Model 750 Tyco/Raychem TG-33 Tyco/Raychem
CV-5000 Model 750B Tyco/Raychem TG-33 Tyco/Raychem
Table 50
ALTERNATIVE HOT AIR GUNS
Specified Hot Air Gun Alternative Hot Air Gun
Part Number Supplier Part Number Supplier
CV-5000 Model 500 Tyco/Raychem
HG-501A Master Appliance
CV-5000 Model 500B Tyco/Raychem
CV-5000 Model 500B Tyco/Raychem HG-501A Master Appliance
CV-5000 Model 750 Tyco/Raychem
CV-5000 Model 750B Tyco/Raychem
HG-S-751-10 Master Appliance
CV-5000 Model 750B Tyco/Raychem HG-S-751-10 Master Appliance
E. Splice Assembly Materials
Table 51
HEAT SHRINKABLE SLEEVES
Temperature Grade Fluid Class Description
B 1 Refer to Heat Shrinkable Sleeves in Subject 20-00-11.
D 1 Refer to Heat Shrinkable Sleeves in Subject 20-00-11.
ASSEMBLY OF SPLICES
707, 727-787
