Table 52
PTFE AND TFE TAPES
Temperature Grade Description
B Refer to PTFE and TFE Tapes in Subject 20-00-11.
C Refer to PTFE and TFE Tapes in Subject 20-00-11.
D Refer to PTFE and TFE Tapes in Subject 20-00-11.
Table 53
SILICONE TAPES
Temperature Grade Description
C Refer to Silicone Tapes in Subject 20-00-11.
D Refer to Silicone Tapes in Subject 20-00-11.
Table 54
INSULATION FILM STRIPS
Temperature Grade Part Number Supplier
D
E125-2
Fluorglas
Saint Gobain Performance Plastics
E125-3
Fluorglas
Saint Gobain Performance Plastics
P-412 Permacel
Scotch 48 3M
Scotch 3082 3M
Scotch 4202 3M
Table 55
SOLDER SLEEVE PART NUMBERS
Minimum O.D. of the Jacket
(inch)
Minimum O.D. of the Shield
(inch)
Solder Sleeve
Part Number Supplier
0.095 0.020 D-144-25 Raychem
0.105 0.020 BACS13CT1N Boeing
0.145 0.030
BACS13CT2N Boeing
M83519/1-2 QPL
0.200 0.050
BACS13CT3N Boeing
M83519/1-3 QPL
