• The tape layers include the crimp barrel of the terminal
• The tape layers make a 50 percent minimum overlap
• The length of the tape layers on the wire insulation is approximately 1.0 inch.
(c) Assemble a wire harness tie near each end of the tape layers to hold the layers in their
position.
M. Assembly of M7928/1 Terminal Lugs
Refer to Paragraph 1.J. for the description of the M7928/1 terminal lugs.
Table 66
CRIMP TOOLS FOR M7928/1 TERMINAL LUGS
Crimp Barrel Size
Crimp Tool
Basic Unit Head Die Set
26 59275 - -
24
565435-5 567200-2 69878
59275 - -
68075 - 69878
69692-1 - -
69875 - 69878
22
46110 - -
4B2-457540-6 687658-1 69872
59250 - -
68075 - 69872
69004 - 47451
69005 - -
69118-() - 45185-7
69365-() - 47806-2
69875 - 69872
20
565435-5 567200-2 69872
59250 - -
69692-1 - -
18
565435-5 567200-2 69872
59250 - -
69319-1 - 47806-2
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 95
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
