Table 66 CRIMP TOOLS FOR M7928/1 TERMINAL LUGS (Continued)
Crimp Barrel Size
Crimp Tool
Basic Unit Head Die Set
16
46110 - -
59250 - -
68075 - 69873
69004 - 47852
69005 47517 -
69118-() - 45225-2
69118-() - 45225-5
69365-() - 47807-1
69875 - 69873
14
565435-5 567200-2 69872
69693-1 - -
12
59239-() - -
68075 - 69874 Model C
69004 - 47453
69010 47518-1 -
69365 - 47808
69365-() - 47808-6
69875 - 69874 Model C
10
565435-5 567200-2 69874
69365-() - 47807-1
NOTE: Refer to Table 40 for the part numbers of the recommended Power Pumps.
NOTE: Refer to Subject 20-30-22 for the assembly of a terminal lug with a conductor that is smaller
than the crimp barrel size of the terminal lug.
(1) Make a selection of a terminal lug from Table 22.
NOTE: For the selection of the terminal, use:
• The crimp barrel size, if one wire is to be terminated
• The CAU range, if more than one wire is to be terminated.
NOTE: Refer to Subject 20-30-22 if more than one wire is to be terminated.
(2) Make a selection of a crimp tool from Table 66.
(3) Remove the necessary length of the insulation from the end of the wire.
Refer to Subject 20-00-15 for the insulation removal procedures.
Make sure that:
• When the wire is in the terminal lug, and the end of the wire insulation is in the insulation
grip of the terminal lug, the end of the conductor extends farther than the end of the crimp
barrel
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 96
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
