Boeing 707 - Assembly of Terminal Lugs; Crimp Tool Power Pumps and Heads

Table 39
ALTERNATIVE TERMINAL LUGS
Specified Terminal Lug Alternative Terminal Lug
Part Number Supplier Part Number Supplier
51927 Tyco/AMP
BACT12AM5-10 Boeing
50847 Tyco/AMP
2. ASSEMBLY OF TERMINAL LUGS
A. Crimp Tool Power Pumps and Heads
Table 40
CRIMP TOOL POWER PUMPS
Power Pump
Maximum Pressure
(psi)
13597 10,000
13600 10,000
69120-() 8400
Y6NP 6000
NOTE: Other power pumps than those shown in Table 40 can be used. A power pump must obey the
minimum and maximum pressures shown in Table 41 for the specified crimp tool head.
Table 41
SATISFACTORY PRESSURES FOR THE OPERATION OF CRIMP TOOL HEADS
Crimp Tool Head
Pressure
(psi)
Supplier Part Number Minimum Maximum
Tyco/AMP
58422-1 8000 8400
69051 8000 8400
69061 8000 8400
69066 8000 8400
69069 8000 8400
Boeing ST970-12 8000 8400
Burndy
Y29B 5700 6000
Y34A 5700 6000
Y35BH 9500 10500
Daniels
BDHD1 8500 9000
PPFC-1H 8500 9000
TBHD1 8500 9000
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 46
Feb 15/2016D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
