(1) If one build-up sleeve is specified, put a 1.0 inch ±0.1 inch length of the specified sleeve on the
applicable wiring. Refer to Table 3.
(2) If two build-up sleeves are specified, put the specified sleeves on the applicable wiring. Refer to
Table 3.
(a) Put a 0.9 inch ±0.1 inch length of the larger sleeve on the wiring
(b) Put a 1.0 inch ±0.1 inch length of the other sleeve on the wiring
(3) Prepare the end of each cable:
(a) Remove the necessary length of jacket from the end of the cable to make the distance from
the end of the jacket to the end of the cable equal to dimension A or dimension A'.
Refer to Subject 20-00-15 for the procedure to remove the cable jacket.
(b) Remove the necessary length of shield to make the distance from the end of the jacket to
the end of the shield equal to dimension B or dimension B'.
(c) If it is specified, fold the shield back. Refer to Table 7.
(d) For each wire in the cable, remove the necessary length of insulation to make the distance
from the end of the insulation to the end of the conductor equal to dimension C or dimension
C'.
Refer to Subject 20-00-15 for the procedure to remove the insulation.
(e) If it is specified, fold the conductor back. Refer to Table 7.
(4) Put the solder shield splice sleeve on the cable or cables that are on the end of the splice
assembly that has the smallest number of cables or the cable with the smallest diameter.
Make sure that the small end of the sleeve is put on first.
D. Assembly of the Conductor Splice
Table 8
CONDUCTOR SPLICE CRIMP TOOLS
Crimp Barrel Size Type Basic Unit Die
Die or Nest
Color
Supplier
20-26
Hand
AD-1377 - Red Tyco Electronics
GMT-232 - Red Daniels
ST956C - Red Boeing
ST956D - Red Boeing
Power PMTB-232 - Red Daniels
16-20
Hand
AD-1377 - Blue Tyco Electronics
GMT-232 - Blue Daniels
ST956C - Blue Boeing
ST956D - Blue Boeing
Power PMTB-232 - Blue Daniels
ASSEMBLY OF BACS52R SHIELDED SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-19
Page 30
Oct 15/2017D6-54446
