C. Circular Area Units of Splices
Table 3
CAU OF BUTT SPLICES
Crimp Barrel
Size
CAU Splice
Minimum Maximum Type
Specification or
Standard
Description
26-22 3 8 Insulated NAS1388-() With Insulation Grip
24-20 4 12 Insulated NAS1388-() With Insulation Grip
22-18
7 24 Insulated NAS1388-() With Insulation Grip
5 20
Uninsulated
BACT12C() No Insulation Grip
7 24 NAS1387-() No Insulation Grip
16-14 15 51
Insulated NAS1388-() With Insulation Grip
Uninsulated
BACT12C() No Insulation Grip
NAS1387-() No Insulation Grip
12-10 43 138
Insulated NAS1388-() With Insulation Grip
Uninsulated
BACT12C() No Insulation Grip
NAS1387-() No Insulation Grip
8 132
208 Insulated NAS1389-() No Insulation Grip
181 Uninsulated BACT12C() No Insulation Grip
6
209 331 Insulated NAS1389-() No Insulation Grip
206 288 Uninsulated BACT12C() No Insulation Grip
4
332 526 Insulated NAS1389-() No Insulation Grip
327 457 Uninsulated BACT12C() No Insulation Grip
2
527 837 Insulated NAS1389-() No Insulation Grip
524 735 Uninsulated BACT12C() No Insulation Grip
1/0
838 1195 Insulated NAS1389-() No Insulation Grip
975 1119 Uninsulated BACT12C() No Insulation Grip
2/0 1049 1458 Uninsulated BACT12C() No Insulation Grip
3/0 1323 1810 Uninsulated BACT12C() No Insulation Grip
4/0 1666 2257 Uninsulated BACT12C() No Insulation Grip
ASSEMBLY OF TERMINALS AND SPLICES UNDER SPECIAL CONDITIONS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-22
Page 6
Oct 15/2015D6-54446
