Boeing 707 - Page 991

Table 2 CAU OF TERMINALS (Continued)
Crimp Barrel
Size
CAU Terminal
Minimum Maximum Type
Specification or
Standard
Description
6
209 331 Insulated BACT12AC() With Insulation Grip
206 288 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
4
332 526 Insulated BACT12AC() With Insulation Grip
327 457 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
2
527 837 Insulated BACT12AC() With Insulation Grip
524 735 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
1 662 878 Uninsulated
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
1/0
838 1195 Insulated BACT12AC() With Insulation Grip
831 1119 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
2/0
1196 1505 Insulated BACT12AC() With Insulation Grip
1049 1458 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
3/0 1323 1810 Uninsulated
BACT12E() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
4/0
1901 2310 Insulated BACT12AC() With Insulation Grip
1666 2257 Uninsulated
BACT12E() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
ASSEMBLY OF TERMINALS AND SPLICES UNDER SPECIAL CONDITIONS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-22
Page 5
Oct 15/2015D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
