Boeing 707 - Conductor Splice Part Numbers; Splice Assembly Wiring Build-Up Sleeves and Filler Wires

C. Conductor Splice Part Numbers
Table 3
CONDUCTOR SPLICE PART NUMBERS
Part Number Crimp Barrel Size Color Code Supplier
BACS52K1 26-20 Red Tyco
BACS52K1N 26-20 Red Tyco
BACS52K2 20-16 Blue Tyco
BACS52K2N 20-16 Blue Tyco
BACS52K3 16-12 Yellow Tyco
BACS52K3N 16-12 Yellow Tyco
BACS52K4 12-10 - Tyco
BACS52K4N 12-10 - Tyco
D. Splice Assembly Wiring Build-Up Sleeves and Filler Wires
Table 4
WIRING BUILD-UP SLEEVES
Splice Kit
One Side of Splice Assembly Other Side of Splice Assembly
Wiring
Build-Up
Sleeve
Wiring
Build-Up
Sleeve
BACS52T1N2D BMS13-80T01C02G024 WTF1204
BMS13-80T01C02G024
BMS13-80T01C02G024
-
BACS52T1T2D BMS13-80T01C02G024 WTF1204
BMS13-80T01C02G024
BMS13-80T01C02G024
-
BACS52T2N3D BMS13-60T49C03G020 WTF1204
BMS13-60T49C03G020
BMS13-60T49C02G020
-
BACS52T2N3D BMS13-78T05C03G016 - BMS13-60T52C03G020 WTF1204
BACS52T2N3D BMS13-78T05C03G018 - BMS13-60T52C03G020 WTF1204
BACS52T2T1B BMS13-48T27C01G018 - BMS13-48T27C01G022 WTF1204
BACS52T2T2D BMS13-48T38C02G020 WTF1205
BMS13-48T38C02G020
BMS13-48T38C02G020
-
BACS52T3N2D BMS13-60T17C02G012 - BMS13-60T50C02G022 WTF1204
BACS52T3N2D BMS13-60T52C02G016 WTF1204
BMS13-60T52C02G016
BMS13-60T52C02G016
-
BACS52T3N2D BMS13-60T52C02G016 WTF1204
BMS13-60T52C02G016
BMS13-60T52C02G020
-
BACS52T3N3D BMS13-60T20C03G012 - BMS13-60T17C03G018 WTF1204
BACS52T3N3D BMS13-60T20C03G012 - BMS13-60T20C03G020 WTF1204
BACS52T3N3E BMS13-60T52C03G012 WTF1205
BMS13-60T52C03G016
BMS13-60T52C03G016
-
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 14
Feb 15/2021D6-54446
