Boeing 707 - Assembly of Dual Hole, Upright, and Heavy Duty Terminal Lugs

(b) Turn the terminal lug one flat, approximately 60 degrees.
(c) Crimp the terminal lug again.
Make sure that the second crimp is in the same location along crimp barrel as the first
crimp.
O. Assembly of Dual Hole, Upright, and Heavy Duty Terminal Lugs
Refer to Paragraph 1.L. for the description of the dual hole, upright, and heavy duty terminal lugs.
Table 70
INDENTER TYPE CRIMP TOOLS FOR DUAL HOLE TERMINAL LUGS
Crimp Barrel Size
Crimp Tool
Basic Unit Head Adapter Nest Indenter
6
BAT35 - Y35P3 UV6L Y34PLA
Power Pump
Y29B - DV6L Y29PL
Y35BH Y35P3 UV6L Y34PLA
Y35 - Y35P3 UV6L Y34PLA
4
BAT35 - Y35P3 UV4L Y34PLA
Power Pump
69069 - 47321 47322
Y29B - DV4L Y29PL
Y35BH Y35P3 UV4L Y34PLA
Y35 - Y35P3 UV4L Y34PLA
2
BAT35 - Y35P3 UV2L Y34PLA
Power Pump
Y29B - DV2L Y29PL
Y35BH Y35P3 UV2L Y34PLA
Y35 - Y35P3 UV2L Y34PLA
1/0
BAT35 - Y35P3 UV25L Y34PA
Power Pump
Y29B - DV25L Y29PR
Y35BH Y35P3 UV25L Y34PA
Y35 - Y35P3 UV25L Y34PA
2/0
BAT35 - Y35P3 UV26L Y34PA
Power Pump
Y29B - DV26L Y29PR
Y35BH Y35P3 UV26L Y34PA
Y35 - Y35P3 UV26L Y34PA
3/0
BAT35 - Y35P3 UV27L Y34PA
Power Pump
13642M - ST2354-16 ST2354-13
Y29B - DV27L Y29PR
Y35BH Y35P3 UV27L Y34PA
Y35 - Y35P3 UV27L Y34PA
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 105
Feb 15/2020D6-54446
