Boeing 707 - AMP Copalum Terminal Part Numbers; Part Numbers and Description

This Subject gives the procedures to assemble these terminals with aluminum or copper wire:
• AMP (Tyco) copalum terminals
• BACT12AW, BACT12AY, BACT13K, BACT13L and BACT13T copalum terminals
• MS25435-() aluminum terminals
• Thomas & Betts aluminum terminals.
Refer to Subject 20-30-07 for the procedures to assemble these aluminum terminals with aluminum wire:
• BACT12BC()
• BACT12BD()
• BACT12BE()
• BACT12BF()
• BACT12BG().
1. PART NUMBERS AND DESCRIPTION
For BACT12AW, BACT12AY, BACT13K, BACT13L and BACT13T copalum terminals refer to Paragraph
1.B..
A. AMP Copalum Terminal Part Numbers
Table 1
AMP COPALUM TERMINAL PART NUMBERS
Crimp Barrel
Stud
Size
Tongue Configuration Plating Part Number Supplier
Aluminum Wire
Size
(AWG)
Copper Wire
Size
(AWG)
8 10
10
Standard Tin 277147-1 Tyco/AMP
Narrow Tin 277147-5 Tyco/AMP
1/4 Standard Tin 277147-3 Tyco/AMP
5/16 Standard Tin 277147-4 Tyco/AMP
6 8
8 Standard Tin 277148-5 Tyco/AMP
10
Standard Tin 277148-1 Tyco/AMP
Narrow Tin 277154-1 Tyco/AMP
1/4
Standard Tin 277148-2 Tyco/AMP
Narrow Tin 277148-7 Tyco/AMP
Two Stud Holes Tin 55832-1 Tyco/AMP
5/16 Standard Tin 277148-3 Tyco/AMP
3/8
Standard Tin 277148-4 Tyco/AMP
Two Stud Holes Tin 55832-2 Tyco/AMP
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-14
Page 2
Oct 15/2015D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
