Boeing 707 - Selection of an Insulation Sleeve

Table 17
CRIMP TOOLS FOR BACT13T TERMINAL LUGS
Terminal Lug
Crimp Barrel Size
(Part Mart)
Crimp Tool
Power Unit Head Die Set
BACT13T-5A60 1/0AL 13-60 69120
1752787-1
68010-258422-1
69066
BACT13T-5A78 1/0AL 13-78 69120
1752787-1
68010-258422-1
69066
BACT13T-6A78 2/0AL 13-78 69120
1752787-1
68011-1
58422-1
69066 314964-1
BACT13T-7A78 3/0AL 13-78 69120
1752787-1
59877-1
58422-1
BACT13T-8A78 4/0AL 13-78 69120
1752787-1
314948-1
58422-1
(1) Make a selection of insulation sleeve. Refer to Paragraph 2.F..
(2) Remove the necessary length of wire insulation.
Refer to:
• Table 16
• Subject 20-00-15 for the procedures to remove the insulation.
(3) Make a selection of a power unit, crimp tool head, and die set from Table 11. Refer to Paragraph
2.H. for terminal assembly process.
F. Selection of an Insulation Sleeve
Table 18
3M COLD SHRINKABLE SLEEVES
Wire Size
(AWG)
Cold Shrinkable Sleeve
Special Instructions
Part Number Supplier
6 8443-2.0 3M
3 layers of tape are necessary before the cold
shrinkable sleeve is installed
4 8443-2.0 3M -
2 8445-2.5 3M -
1/0 8445-2.5 3M -
2/0 8447-3.2 3M -
3/0 8447-3.2 3M -
4/0 8447-3.2 3M -
