(7) If the wire comes out of the terminal lug:
(a) Set the insulation adjustment to the subsequent position that is more tight.
(b) Use a new terminal lug to do Step 2.B.(2) through Step 2.B.(6) again.
Make sure that:
• The insulation adjustment pins are in the same position
• The adjustment is not more tight than is sufficient.
C. Assembly of a Cable Shield in a Terminal Lug
Table 42
LOCATION OF THE CAU DATA FOR SHIELDS OF SHIELDED WIRES AND CABLES
Wire Type Code Location of the Shield CAU Data
C1 Table 50
C2 Table 50
C3 Table 50
C4 Table 50
C9 Table 43
DU Table 43
D2 Table 43
D3 Table 43
D4 Table 43
D6 Table 43
D7 Table 43
D9 Table 43
FF Table 43
GE Table 44
GF Table 44
GG Table 44
GH Table 44
GP Table 44
GQ Table 44
GR Table 44
GT Table 46
GU Table 44
GV Table 44
GW Table 43
G2 Table 43
G7 Table 44
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 48
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
