Table 43 CAU OF THE SHIELD FOR SHIELDED WIRES (Continued)
Shielded Wire CAU
Supplier Specification Type Class AWG
Wire
Type
Code
Inner Shield Outer Shield
Judd
C42016310902 - 1 18 T2 - 13
JW647-99 - 2 20 D9 13 17
Raychem
CTC-0039-20-06090 - 2 20 DU - 16
CTC-0039-22-06090 - 2 22 DU - 15
55A6160-20-06090 - 2 20 2Z 13 23
55A6087-20-06090 - 1 20 4J 10 15
55PC6021-20-06090 - 2 20 D6 16 18
55PC6022-20-06090 - 3 20 D7 16 18
CTC-0062-20-9/5-9 - 2 20 TA - 12
Tensolite 20721/20087Q-2 - 2 20 5T 15 18
Thermax
550-292 - 2 20 D2 28 36
551-292 - 3 20 D3 32 42
552-292 - 2 18 D4 28 42
Table 44
CAU OF THE SHIELD FOR BMS 13-60 TYPES 2 AND 5, WIRE TYPE CODES G7, GE, GF, GG, GH, GP, GQ,
GR, GU, GV, QS, QT, QU, QV, QW AND QX
AWG Class CAU of the Shield
14 1 13
16
1 10
2 15
3 21
18
1 10
2 15
3 18
4 21
20
1 10
2 13
3 15
4 18
22
1 6
2 11
3 12
