Table 42 LOCATION OF THE CAU DATA FOR SHIELDS OF SHIELDED WIRES AND CABLES (Continued)
Wire Type Code Location of the Shield CAU Data
Y7 Table 51
Y8 Table 51
2Z Table 43
4J Table 43
46 Table 43
5T Table 43
7J Table 48
8Q Table 47
8C Table 48
8D Table 48
8E Table 48
8K Table 48
9L Table 43
Table 43
CAU OF THE SHIELD FOR SHIELDED WIRES
Shielded Wire CAU
Supplier Specification Type Class AWG
Wire
Type
Code
Inner Shield Outer Shield
Boeing
10-60816-61 - 1 18 TK 24 32
65B47866-5 - 2 20 RQ 21 23
BMS 13-31 VII 2
18 FF - 28
20 FF - 24
BMS 13-48 32 2 24 46 - 10
BMS 13-55
IV 1 16 9L - 16
III 2 20 C9 - 26
BMS 13-60
25
1 20 HW 10 13
2 20 HX 13 18
27
2
20 M2 13 18
22 M2 11 15
3
20 M3 12 16
18 M3 18 23
15 2 24 G2 - 6
13
4 20 GW - 14
1 20 H5 - 10
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 50
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
