Table 47
CAU OF THE SHIELD FOR BMS 13-48 TYPE 12, WIRE TYPE CODES U4, VF, VG, VH, XQ AND 8Q
AWG Class CAU of the Shield
10 1 21
12
1 17
2 26
3 31
14
1 14
3 20
16
1 12
2 18
3 20
18
1 10
2 17
3 19
4 23
20
1 9
2 14
3 17
4 19
22
1 8
2 12
3 14
Table 48
CAU OF THE SHIELD FOR BMS 13-48 TYPE 24, WIRE TYPE CODES 7J, 8C, 8D, 8E AND 8K
CAU Class CAU of the Shield
16
2 19
3 23
18
1 12
2 18
3 21
4 23
20
1 10
2 15
3 18
4 21
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
