Boeing 707 - Page 120

Table 49
CAU OF THE SHIELD FOR BMS 13-48 TYPE 15, WIRE TYPE CODES OA AND OC
AWG Class CAU of the Shield
12 1 17
14
1 14
3 28
Table 50
CAU OF THE SHIELD FOR TLS-200-()-20NA, WIRE TYPE CODES C1, C2, C3 AND C4
AWG Class
CAU
Inner Shield Outer Shield
20
1 13
-
18
2 18 -
4 26 -
Table 51
CAU OF THE SHIELD FOR BMS 13-48 TYPE 32, WIRE TYPE CODES Y6, Y7 AND Y8
AWG Class CAU of the Shield
16
1 12
2 18
3 20
18
1 10
2 17
3 19
20
1 9
2 14
3 17
22
1 8
2 12
3 14
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 54
Feb 15/2016D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
