L. Preparation of the Tyco 58422-1 Hydraulic Crimp Tool
WARNING
DO NOT ACCIDENTLY PRESS THE FOOT PEDAL OR THE HANDLE CONTROL
WHILE THE DIES ARE REMOVED OR INSTALLED. AN INJURY TO PERSONNEL
CAN OCCUR.
WARNING
DO NOT INSTALL DIFFERENT DIES FROM DIFFERENT DIE SETS IN A CRIMP
TOOL HEAD. AN INJURY TO PERSONNEL CAN OCCUR.
POSITION OF THE TAPE ON THE BOTTOM SURFACE OF THE TONGUE
Figure 30
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-14
Page 38
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
