CAUTION
DO NOT INSTALL DIFFERENT DIES FROM DIFFERENT DIE SETS IN A CRIMP
TOOL HEAD. DAMAGE TO THE EQUIPMENT CAN OCCUR.
TYCO 58422-1 HYDRAULIC CRIMP TOOL
Figure 31
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-14
Page 39
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
