Boeing 707 - Shield-Kon Crimp Tools

Table 47 FERRULE CRIMP TOOLS (Continued)
Outer Ferrule
Crimp Tool
Basic Unit
Die
Part Number Cavity
BACS13S460C
44-000 44-148 -
612648 612909 -
620175 620314 -
HX-4 Y148 -
M22520/5-01 M22520/5-53 -
ST2966M - 14
ST965-6 - L
WT215-20 - L
WT220 - -
WT540 5456 -
BACS13S500C
44-000 44-149 -
612648 612977 -
620175 620300 -
HX-4 Y149 -
M22520/5-01 M22520/5-21 -
ST2966M - 15
ST965-23 - -
WT223 - -
WT540 5457 -
C. Shield-Kon Crimp Tools
Table 48
CRIMP TOOLS FOR THE SHIELD-KON
Shield-Kon Part
Number
Shield Diameter
(inch)
Crimp Tool
Minimum Maximum
Basic Unit
Die Set
Part Number Type
RSK101 0.050 0.070
13300 Pneumatic 101A
WT740 Hand 101A
RSK101 0.070 0.090
13300 Pneumatic 101B
WT740 Hand 101B
RSK201 0.090 0.100
13300 Pneumatic 201C
WT740 Hand 201C
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 51
Feb 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
