Table 48 CRIMP TOOLS FOR THE SHIELD-KON (Continued)
Shield-Kon Part
Number
Shield Diameter
(inch)
Crimp Tool
Minimum Maximum
Basic Unit
Die Set
Part Number Type
RSK201 0.100 0.118
13300 Pneumatic 201D
WT740 Hand 201D
RSK201 0.119 0.131
13300 Pneumatic 201E
WT740 Hand 201E
RSK201 0.132 0.143
13300 Pneumatic 201F
WT740 Hand 201F
RSK301 0.143 0.185
13300 Pneumatic 301H
WT740 Hand 301H
RSK301 0.144 0.162
13300 Pneumatic 301G
WT740 Hand 301G
RSK301 0.186 0.201
13300 Pneumatic 301J
WT740 Hand 301J
RSK401 0.200 0.230
13300 Pneumatic 401K
WT740 Hand 401K
RSK401 0.231 0.250
13300 Pneumatic 401L
WT740 Hand 401L
RSK401 0.251 0.275
13300 Pneumatic 401M
WT740 Hand 401M
RSK401 0.276 0.300
13300 Pneumatic 401N
WT740 Hand 401N
SK501HT 0.301 0.325
HX4 Hand 501P
M22520/5-01 Hand 501P
SK601HT 0.401 0.425
HX4 Hand 601Q
M22520/5-01 Hand 601Q
NOTE: SK501HT and SK601HT are no longer manufactured.
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 52
Feb 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
