Table 15 INSTALLATION TORQUE FOR EXTERNAL POWER CONNECTOR TERMINALS (Continued)
External Power Connector
Fastener Torque
(inch-pounds)
Part Number
Fastener
Terminal
Identification
Minimum Maximum
Thread Size Configuration
BACC65BL-1
3/8-24 Bolt
A 240 300
B 240 300
C 240 300
N 240 300
10-32 Nut
E 15 25
F 15 25
BACC65BL-2
3/8-24 Bolt
A 240 300
B 240 300
E 240 300
F 240 300
10-32 Nut
C 15 25
N 15 25
K. Installation Torque for the Fuel Quantity Probe Terminals
Table 16
INSTALLATION TORQUE FOR FUEL QUANTITY PROBE TERMINALS
Wire Color Terminal Size
Maximum Torque
(inch-pound)
Red 10-32 13
Black 8-32 10
White 6-32 10
ELECTRICAL CONNECTION OF EQUIPMENT AND INSTALLATION OF TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-00
Page 29
