8. SEALED SPLICE CONFIGURATIONS FOR UNSHIELDED WIRES AND UNSHIELDED CABLES FOR
HIGH TEMPERATURE
A. Splice Assembly Configurations
For the conditions that are applicable for:
• The repair of a wire or a cable with a splice, refer to Subject 20-10-13
• The selection of the correct sealed splice configuration, refer to Paragraph 1.C.
To calculate the CAU of the conductor, refer to Table 4.
Table 78
SEALED SPLICE ASSEMBLY CONFIGURATIONS FOR HIGH TEMPERATURE
One End of
Splice
Assembly
Other End of
Splice
Assembly
CAU Range
Applicable
Condition
Splice Assembly
Minimum Maximum Configuration Procedure
One Wire One Wire 5 138
Fuel Vapor Tape, Ties Paragraph 8.B.
No Fuel Vapor
Tape, Sleeve Paragraph 8.C.
Tape, Ties Paragraph 8.B.
One Wire Two Wires 5 138
Fuel Vapor Tape, Ties Paragraph 8.D.
No Fuel Vapor
Tape, Sleeve Paragraph 8.E.
Tape, Ties Paragraph 8.D.
Two Wires Two Wires 5 138
Fuel Vapor Tape, Ties Paragraph 8.F.
No Fuel Vapor
Tape, Sleeve Paragraph 8.G.
Tape, Ties Paragraph 8.F.
One Cable One Cable 5 138
Fuel Vapor Tape, Ties Paragraph 8.H.
No Fuel Vapor
Tape, Sleeve Paragraph 8.I.
Tape, Ties Paragraph 8.H.
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 119
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
