Table 77 SPLICE PART NUMBERS FOR IN-LINE RESISTORS AND DIODES (Continued)
Resistor or Diode Wire Gauge Splice
RNC70( ) 24-20 D-609-06
RNC70( ) 18-16 D-609-07
RNC75( ) 24-20 D-609-06
RNC75( ) 18-16 D-609-07
RNC77( ) 24-20 D-609-06
RNC77( ) 18-16 D-609-07
RW69( ) 24-20 D-609-06
RW69( ) 18-16 D-609-07
RW74( ) 24-20 D-609-06
RW74( ) 18-16 D-609-07
RWR71( ) 26-20 D-609-06
RWR78( ) 24-20 D-609-06
RWR78( ) 18-16 D-609-07
RWR80( ) 26-20 D-609-06
RWR81( ) 26-20 D-609-06
RWR82( ) 26-20 D-609-06
RWR84( ) 24-20 D-609-06
RWR84( ) 18-16 D-609-07
RWR89( ) 24-20 D-609-06
RWR89( ) 18-16 D-609-07
(a) Prepare the end of the wires that will terminate to the applicable splices in accordance with
Subject 20-30-12.
(b) Put a 2.50 ±0.13 inches in length of smallest diameter DWP-125 sleeve on one wire.
(c) Make an identification sleeve with the resistor or diode equipment number in accordance
with the Subject 20-10-11.
(d) Put the Identification sleeve on to the wire that does not have the DWP-125 sleeve.
(e) Terminate the applicable splice on to each end of the resistor or diode in accordance with
Table 1/ASSEMBLY PROCEDURES FOR SPECIFIED SPLICES and Subject 20-30-12.
(f) Solder the crimped leads to the splice barrel.
(g) Terminate the connecting wires to the other end of the splices in accordance with
Subject 20-30-12. Refer to Figure 1.
(h) Install the DWP-125 heat shrinkable sleeve on the assembly in accordance with
Subject 20-10-14. Refer to Figure 1. Make sure the sleeve is approximately centered on the
assembly
(i) Install the identification sleeve on the assembly in accordance with SSubject 20-10-14.
Refer to Figure 1. Make sure the identification sleeve is approximately centered on the
DWP-125 sleeve
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 118
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
