• The end of the conductor extends farther than the end of the crimp barrel
• The maximum distance from the end of the wire insulation of a single wire to the end of the
crimp barrel is 0.12 inch for AWG 10 and smaller, and 0.25 inch for AWG 8 and larger
• If two flag terminals are on the wire, the crimp of the flag terminal nearest to the end of the
wire is made first
• If two flag terminals are on the wire, the distance between the terminal lugs is correct for the
installation.
NOTE: If two flag terminals are on the wire, the crimp of the flag terminal at the end of the wire
completed first, keeps the strands of the conductor together until the crimp of both flag
terminals is completed.
(9) If a length of heat shrinkable sleeve is on the wire, shrink it into its position.
Make sure that the end of the heat shrinkable sleeve is aligned with the end of the wire insulation.
NOTE: This keeps the strands of the insulation braid together.
L. Assembly of BACT12M, and 280U0010-1 Terminal Lugs
Refer to Paragraph 1.H. for the description of the BACT12M, and the 280U0010-1 terminal lugs.
Table 63
CRIMP TOOLS FOR SMALL BACT12M TERMINAL LUGS
Crimp Barrel Size
Crimp Tool
Basic Unit Holder Head Die
22-18
1213804-1
(Battery powered)
1213757-1 46673 -
1213875-1
(Battery powered)
1213757-1 46673 -
189721-1 356302-1 356744-1 -
314590-() - - 314542-1
314590-() - - 314542-2
314700-() - - 314542-1
314700-() - - 314542-2
46673 - - -
69010 - 45175 -
W400-5060 - - 22-18 AWG
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 84
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
