Table 63 CRIMP TOOLS FOR SMALL BACT12M TERMINAL LUGS (Continued)
Crimp Barrel Size
Crimp Tool
Basic Unit Holder Head Die
16-14
189721-1 356302-1 356744-2 -
314590-() - - 314543-1
314590-() - - 314543-2
314700-() - - 314543-1
314700-() - - 314543-2
46988 - - -
59294-() - - -
69010 - 45176 -
W400-5060 - - 16-14 AWG
12-10
189721-1
(Pnuematic powered)
356302-1 217206-1 -
1901235-1
(Battery powered)
1804902-1 59461 -
314937-1 - - 314915-1
46447 - - -
59461 - - -
PHRPU2 - PHST-59461 -
