INDENTER TYPE CRIMP TOOLS FOR LARGE BACT12M AND 280U0010-1 TERMINAL LUGS
Crimp
Barrel Size
Crimp Tool
Basic Unit Head Adapter Nest Indenter Special Instructions
8
1213875-1
(Battery powered)
- - 1490413-1 1490414-1 -
59973-1 - - 48126 48355 -
69020 - - 48126 48355 -
BAT35 - Y35P3 UV8L Y34PL
Use for Burndy terminal
lugs only
M8ND - - - N8CT
Use for Burndy terminal
lugs only
MR8-5 - - - - -
Power Pump
69046 - 47321 47322 -
69069 - 47321 47322 -
BDHD1 - DV8L-1 Y29PL
Use for Burndy terminal
lugs only
Y29B - DV8L-1 Y29PL
Use for Burndy terminal
lugs only
Y35BH Y35P3 UV8L Y34PL
Use for Burndy terminal
lugs only
Y35 - Y35P3 UV8L Y34PL
Use for Burndy terminal
lugs only
Y8ND - - - N8CT
Use for Burndy terminal
lugs only
6
1213875-1
(Battery powered)
- - 1490413-2 1490414-2 -
59973-1 - - 48128 48127 -
69020 - - 48128 48127 -
BAT35 - Y35P3 UV6L Y34PLA
Use for Burndy terminal
lugs only
Power Pump
69046 - 47321 47322 -
69069 - 47321 47322 -
BDHD1 - DV6L Y29PL
Use for Burndy terminal
lugs only
Y29B - DV6L Y29PL
Use for Burndy terminal
lugs only
Y35BH Y35P3 UV6L Y34PLA
Use for Burndy terminal
lugs only
Y35 - Y35P3 UV6L Y34PLA
Use for Burndy terminal
lugs only
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 86
Oct 15/2017D6-54446
