2. SPLICE ASSEMBLY
A. Selection of a Splice Assembly Configuration
For the conditions that are applicable for this section, refer to Paragraph 2.B..
Table 6
CABLE PREPARATION - STANDARD CONFIGURATIONS
Splice Kit Group
Quantity of
Conductor
Splices
Wiring Configuration
Cable Preparation
One End of the Splice Other End of the Splice
T1( )1 1
One Class 1 Cable One Class 1 Cable Paragraph 3.A.
One Class 1 Cable One Class 2 Cable Paragraph 3.C.
One Class 1 Cable Two Class 1 Cables Paragraph 3.B.
One Class 2 Cable One Class 3 Cable Paragraph 3.D.
Two Class 1 Cables Two Class 1 Cables Paragraph 3.E.
T1( )2 2
One Class 2 Cable One Class 2 Cable Paragraph 3.G.
One Class 2 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.I.
One Class 2 Cable Two Class 1 Cables Paragraph 3.H.
One Class 2 Cable Two Class 2 Cables Paragraph 3.J.
One Class 2 Cable and
One Class 1 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.N.
One Class 2 Cable and
One Class 1 Cable
Two Class 1 Cables Paragraph 3.F.
Two Class 2 Cables Two Class 2 Cables Paragraph 3.K.
T2( )1 1
One Class 1 Cable One Class 1 Cable Paragraph 3.A.
One Class 1 Cable One Class 2 Cable Paragraph 3.C.
One Class 1 Cable Two Class 1 Cables Paragraph 3.B.
One Class 2 Cable One Class 3 Cable Paragraph 3.D.
Two Class 1 Cables Two Class 1 Cables Paragraph 3.E.
T2( )2 2
One Class 2 Cable One Class 2 Cable Paragraph 3.G.
One Class 2 Cable Two Class 1 Cables Paragraph 3.H.
One Class 2 Cable Two Class 2 Cables Paragraph 3.J.
One Class 2 Cable and
One Class 1 Cable
Two Class 2 Cables Paragraph 3.L.
One Class 2 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.I.
One Class 2 Cable and
One Class 1 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.N.
Two Class 2 Cables Two Class 2 Cables Paragraph 3.K.
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 16
Oct 15/2020D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
