Table 6 CABLE PREPARATION - STANDARD CONFIGURATIONS (Continued)
Splice Kit Group
Quantity of
Conductor
Splices
Wiring Configuration
Cable Preparation
One End of the Splice Other End of the Splice
T2( )3 3
One Class 3 Cable One Class 3 Cable Paragraph 3.R.
One Class 3 Cable Two Class 3 Cables Paragraph 3.O.
One Class 3 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.S.
One Class 3 Cable
One Class 3 Cable and
One Class 2 Cable
Paragraph 3.Q.
Two Class 3 Cables Two Class 3 Cables Paragraph 3.P.
T2( )4 4
One Class 4 Cable One Class 4 Cable Paragraph 3.U.
One Class 4 Cable Two Class 4 Cables Paragraph 3.V.
T3( )1 1
One Class 1 Cable One Class 1 Cable Paragraph 3.A.
One Class 1 Cable One Class 3 Cable Paragraph 3.T.
One Class 1 Cable Two Class 1 Cables Paragraph 3.B.
Two Class 1 Cables Two Class 1 Cables Paragraph 3.E.
T3( )2 2
One Class 2 Cable One Class 2 Cable Paragraph 3.G.
One Class 2 Cable Two Class 1 Cables Paragraph 3.H.
One Class 2 Cable Two Class 2 Cables Paragraph 3.J.
One Class 2 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.I.
One Class 2 Cable and
One Class 1 Cable
Two Class 2 Cables Paragraph 3.L.
One Class 2 Cable and
One Class 1 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.N.
Two Class 2 Cables Two Class 2 Cables Paragraph 3.K.
Two Class 2 Cables
Two Class 2 Cables,
Split Configuration
Paragraph 3.M.
T3( )3 3
One Class 3 Cable One Class 3 Cable Paragraph 3.R.
One Class 3 Cable Two Class 3 Cables Paragraph 3.O.
Two Class 3 Cables Two Class 3 Cables Paragraph 3.P.
T4( )1 1
One Class 1 Cable One Class 1 Cable Paragraph 3.A.
One Class 1 Cable Two Class 1 Cables Paragraph 3.B.
Two Class 1 Cables Two Class 1 Cables Paragraph 3.E.
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
