Table 6 CABLE PREPARATION - STANDARD CONFIGURATIONS (Continued)
Splice Kit Group
Quantity of
Conductor
Splices
Wiring Configuration
Cable Preparation
One End of the Splice Other End of the Splice
T4( )2 2
One Class 2 Cable One Class 2 Cable Paragraph 3.G.
One Class 2 Cable Two Class 1 Cables Paragraph 3.H.
One Class 2 Cable Two Class 2 Cables Paragraph 3.J.
One Class 2 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.I.
One Class 2 Cable and
One Class 1 Cable
One Class 2 Cable and
One Class 1 Cable
Paragraph 3.N.
Two Class 2 Cables Two Class 2 Cables Paragraph 3.K.
Two Class 2 Cables
Two Class 2 Cables,
Split Configuration
Paragraph 3.M.
NOTE: In Table 7, Side of Splice A is one end of the splice, and Side of Splice B is the other end of the
splice.
Table 7
CABLE PREPARATION - SPECIAL CONFIGURATIONS
Splice Kit
Group
Side of
Splice
Cable Configuration Special Instructions Cable Preparation
T2( )1
A
1 Class 1 Cable, AWG 22 or AWG
24 Conductor
Fold the conductor back
Paragraph 4.A.
B
2 Class 1 Cables, AWG 22 or AWG
24 Conductor
-
T2( )1
A
1 Class 1 Cable, AWG 22 or AWG
24 Conductor
Fold the conductor back
Paragraph 4.B.
B
1 Class 1 Cable AWG 16, AWG 18,
or AWG 20 Conductor
-
T2( )2
A 1 Class 2 Cable AWG 22 Conductor Fold the conductor back
Paragraph 4.C.
B
2 Class 1 Cables AWG 22
Conductor
Fold the conductor back
T2( )2
A 1 Class 2 Cable AWG 22 Conductor Fold the conductor back
Paragraph 4.D.
B
2 Class 2 Cables AWG 22
Conductor
-
T2( )2
A 1 Class 2 Cable AWG 22 Conductor Fold the conductor back
Paragraph 4.E.
B
1 Class 2 Cable AWG 16, AWG 18,
or AWG 20 Conductor
-
T2( )2
A 1 Class 2 Cable AWG 22 Conductor Fold the conductor back
Paragraph 4.F.
B
1 Class 2 Cable 1 Class 1 Cable
AWG 22 Conductor
-
