Table 7 CABLE PREPARATION - SPECIAL CONFIGURATIONS (Continued)
Splice Kit
Group
Side of
Splice
Cable Configuration Special Instructions Cable Preparation
T2( )3
A 1 Class 3 Cable AWG 22 Conductor Fold the conductors back
Paragraph 4.G.
B
1 Class 2 Cable 1 Class 1 Cable
AWG 22 Conductor
Fold the conductors back
T2( )3
A 1 Class 3 Cable AWG 22 Conductor Fold the conductors back
Paragraph 4.H.
B
1 Class 3 Cable AWG 16, AWG 18,
or AWG 20 Conductor
-
T3( )1
A
1 Class 1 Cable AWG 18 or AWG
20 Conductor
Fold the conductors back
Paragraph 4.A.
B
2 Class 1 Cables AWG 18 or AWG
20 Conductor
-
T3( )1
A
1 Class 1 Cable AWG 18 or AWG
20 Conductor
Fold the conductor back
Paragraph 4.B.
B
1 Class 1 Cable AWG 12 or AWG
14 Conductor
-
T3( )1
A
1 Class 1 Cable AWG 22 Conductor
1 Class 1 Cable AWG 24 Conductor
Fold the conductors back
Paragraph 4.J.
B
1 Class 1 Cable AWG 14 Conductor
1 Class 1 Cable AWG 24 Conductor
-
T3( )1
A 1 Class 1 Cable AWG 18 Conductor Fold the conductors back
Paragraph 4.A.
B
1 Class 1 Cable AWG 18 Conductor
1 Class 1 Cable AWG 22 Conductor
-
T3( )1
A
1 Class 1 Cable AWG 18 or AWG
20 Conductor
Fold the conductor back
Paragraph 4.I.
B 1 Class 3 Cable AWG 20 Conductor -
T3( )1
A
2 Class 1 Cables AWG 22
Conductor
Fold the conductors back
Paragraph 4.J.
B
1 Class 1 Cable AWG 14 Conductor
1 Class 1 Cable AWG 24 Conductor
-
T3( )1
A
2 Class 1 Cables AWG 22
Conductor
Fold the conductors back
Paragraph 4.J.
B
1 Class 1 Cable AWG 18 Conductor
1 Class 1 Cable AWG 20 Conductor
-
T3( )1
A 1 Class 2 Cable AWG 22 Conductor Fold the conductors back
Paragraph 4.J.
B
1 Class 1 Cable AWG 18 Conductor
1 Class 1 Cable AWG 20 Conductor
-
T3( )1
A 2 Class 1 Cable AWG 22 Conductor Fold the conductors back
Paragraph 4.J.
B
1 Class 1 Cable AWG 18 Conductor
1 Class 1 Cable AWG 22 Conductor
-
