Table 7 CABLE PREPARATION - SPECIAL CONFIGURATIONS (Continued)
Splice Kit
Group
Side of
Splice
Cable Configuration Special Instructions Cable Preparation
T3( )2
A
1 Class 2 Cable AWG 18 or AWG
20 Conductor
Fold the conductors back
Paragraph 4.E.
B
1 Class 2 Cable AWG 12 or AWG
14 Conductor
-
T3( )2
A 1 Class 2 Cable AWG 12 Conductor -
Paragraph 4.F.
B
1 Class 2 Cable AWG 20 Conductor
1 Class 1 Cable AWG 16 Conductor
Fold one of the AWG 20
conductors back
T3( )2
A 1 Class 2 Cable AWG 14 Conductor -
Paragraph 4.J.
B
1 Class 1 Cable AWG 20 Conductor
1 Class 1 Cable AWG 16 Conductor
Fold the AWG 20 conductor
back
T3( )2
A
1 Class 2 Cable AWG 20 Conductor
1 Class 1 Cable AWG 20 Conductor
Fold one of the Class 2 cable
conductors back
Paragraph 4.L.
B
1 Class 2 Cable AWG 14 Conductor
1 Class 1 Cable AWG 20 Conductor
-
T3( )2
A
1 Class 2 Cable AWG 18 Conductor
1 Class 1 Cable AWG 20 Conductor
-
Paragraph 4.L.
B
1 Class 1 Cable AWG 18 Conductor
1 Class 2 Cable AWG 20 Conductor
Fold one of the Class 2 cable
conductors back
T3( )3
A
1 Class 3 Cable AWG 18 or AWG
20 Conductor
Fold the conductors back
Paragraph 4.H.
B 1 Class 3 Cable AWG 12 Conductor -
T3( )3
A
One Class 3 Cable AWG 20
Conductor
Fold the conductors back
Paragraph 4.M.
B
One Class 3 Cable AWG 20
Conductor One Class 2 Cable AWG
20 Conductor
Fold one of the Class 3 cable
conductors back
T4( )1
A 1 Class 1 Cable AWG 14 Conductor Fold the conductor back
Paragraph 4.B.
B 1 Class 1 Cable AWG 10 Conductor -
T4( )1
A 1 Class 1 Cable AWG 14 Conductor Fold the conductors back
Paragraph 4.A.
B
2 Class 1 Cables AWG 14
Conductor
-
T4( )1
A
2 Class 1 Cables AWG 16
Conductor
Fold the conductors back
Paragraph 4.J.
B
2 Class 1 Cables AWG 12 and AWG
16 Conductors
-
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
