Table 45
CAU OF THE SHIELD FOR BMS 13-60 TYPES 8 AND 11, WIRE TYPE CODES H9, HE, HF, HG, HP, HQ, HR
AND HS
AWG Class CAU of the Shield
12
1 14
2 28
3 31
14
1 13
2 25
3 27
16
1 10
2 22
3 24
18
1 10
2 20
3 22
4 27
20
1 9
2 18
3 19
4 26
22
2 18
3 20
Table 46
CAU OF THE SHIELD FOR BMS 13-60 TYPE 13, WIRE TYPE CODES GT, H1, H2 AND H3
AWG Class CAU of the Shield
18
1 8
3 16
20
1 7
2 12
3 14
22
1 6
3 12
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
