Table 38 OTHER TERMINAL LUG PART NUMBERS (Continued)
Part Number
Crimp
Barrel
Size
(Wire Size
Range)
(AWG)
CAU Range Insulation Color
Stud
Hole
Size
Material
Style Supplier
Min Max Sleeve Band Body Plating
2-36149-4 20 8 12 Red Red 6 Cu Tin Ring Tyco/AMP
2-36149-5 18 12 19 Red White 6 Cu Tin Ring Tyco/AMP
320381 16-14 15 51 Blue - 6 Cu Tin Hook Tyco/AMP
320634 12-10 43 138 Yellow - 6 Cu Tin Ring Tyco/AMP
322215 1/0 1196 1505 - - 1/4 Cu Tin Flag Tyco/AMP
322220 4/0 1666 2257 - - 3/8 - - Ring Tyco/AMP
323067 12-10 43 138 - - 8 Cu Ni Ring Tyco/AMP
324111 4 327 457 Yellow - 10 Cu Tin Ring Tyco/AMP
324112 2 527 837 Red - 5/16 Cu Tin Ring Tyco/AMP
324113 1/0 1196 1505 Blue - 5/16 Cu Tin Ring Tyco/AMP
324158 22-18 7 24 Red - 2 Cu Tin Ring Tyco/AMP
32456 22-18 7 24 Red - 8 Cu Tin Hook Tyco/AMP
328655 2 524 735 Red - 10 Cu Tin Ring Tyco/AMP
329636 24-20 4 12 - - 2 Cu Tin Ring Tyco/AMP
329951 26-22 3 8 Yellow - 2 Cu Tin Ring Tyco/AMP
50847 12-10 52 131 - - 5/16 Cu Ni Ring Tyco/AMP
51927 12-10 43 138 - - 5/16 - - Ring Tyco/AMP
52124 26-22 3 8 - - 8 Cu Tin Ring Tyco/AMP
52274 16 19 26 Blue Blue 4 Cu Tin Ring Tyco/AMP
52307 22 6 8 Red Green 2 Cu Tin Ring Tyco/AMP
52409 22-18 7 24 Red - 6 Ph-Br Tin Spade Tyco/AMP
52411 22 - 18 7 24 Red - 10 Ph-Br Tin Spade Tyco/AMP
52420 16-14 15 51 Blue - 6 Ph-Br Tin Spade Tyco/AMP
52421-3 16-14 15 51 Blue - 8 Ph-Br Tin Spade Tyco/AMP
53057-1 24 4 5 Yellow Blue 10 Cu Tin Ring Tyco/AMP
53580-1 16 19 26 Blue - 6 Cu Ni Ring Tyco/AMP
54746-1 6 206 288 Blue Blue 10 Cu Tin Ring Tyco/AMP
69B40570-2 2/0 - - - - 3/8 Cu Tin Ring Boeing
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
