Table 36
REPLACEMENT TERMINAL LUGS FOR ROLLS-ROYCE TERMINAL LUGS
Rolls-Royce Terminal Lug
Crimp Barrel Size
(Wire Size Range)
(AWG)
Replacement Terminal Lug
1909156
20 BACT12M5
18 BACT12M5
16 BACT12M8
2509293
22 BACT12M130
20 BACT12M130
18 BACT12M130
16 BACT12M147
NOTE: Refer to Paragraph 1.H. for the BACT12M part numbers.
Table 37
THERMOCOUPLE TERMINAL LUG PART NUMBERS
Part Number
Crimp Barrel
Size
Mark
Stud Hole
Size
Material Style Supplier
1387-3 - CR - Chromel Ring Thermo-Electric
1387-4 - AL - Alumel Ring Thermo-Electric
1-321897-0 22-16 - 8 Chromel Ring Tyco/AMP
1-321898-0 22-16 - 10 Alumel Ring Tyco/AMP
Table 38
OTHER TERMINAL LUG PART NUMBERS
Part Number
Crimp
Barrel
Size
(Wire Size
Range)
(AWG)
CAU Range Insulation Color
Stud
Hole
Size
Material
Style Supplier
Min Max Sleeve Band Body Plating
2-320561-3 16 19 26 Blue Blue 6 Cu Ni Ring Tyco/AMP
2-320561-4 14 27 41 Blue Green 6 Cu Ni Ring Tyco/AMP
2-321670-2 6 206 288 - - 8 - - Ring Tyco/AMP
2-321672-1 2 524 735 - - 8 - - Ring Tyco/AMP
2-323914-2 24 4 5 Yellow Blue 4 Cu Ni Ring Tyco/AMP
2-323916-3 24 4 5 Yellow Blue 8 Cu Tin Ring Tyco/AMP
2-326875-4 24 4 5 Yellow Blue 6 Cu Tin Ring Tyco/AMP
2-326875-5 24 4 5 Yellow Blue 10 Cu Ni Ring Tyco/AMP
2-36149-3 22 6 8 Red Green 6 Cu Tin Ring Tyco/AMP
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 44
Feb 15/2016D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
